ESiEN02–01A PCB Layout
Part 1 – System Outline 1–147
3
1
4
5
8.3 Indoor Units: PCB Numbers and Types
No. and types The table below contains the PCB numbers and types of the indoor units.
Indoor unit PCB 1 PCB 2
FHC35BZ7V1
2P053997-1 (type D) —
FHC45BZ7V1
FHC60BZ7V1
FHYBP35B7V1
2P060444-1 (or EC0060A)
(type F)
—
FHYBP45B7V1
FHYBP60B7V1
FHYBP71B7V1
FHYBP100B7V1
2P060445-1 (or EC0061A )
(type F)
FHYBP125B7V1
FHYC35BZ7V1
2P018671-1 (type A) —
FHYC45BZ7V1
FHYCP35B7V1
2P060443-1 (type E) —
FHYCP45B7V1
FHYCP60B7V1
FHYCP71B7V1
FHYCP100B7V1
FHYCP125B7V1
FDYP125B7V1
3SW00943-1 (type M) 2P060446-1 (or EC0062A)
(type G)
FDYP200B7V1
FDYP250B7V1
FHYP35BV1
2P064849-1 (type Q) —
FHYP45BV1
FHYP60BV1
FHYP71BV1
FHYP100BV1
FHYP125BV1
FUYP71BV17
2P060449-1 (type O) —
FUYP100BV17
FUYP125BV17
FAYP71BV1
2P060448-1 (type R) —
FAYP100BV1
FHYKP35BV1
2P060447-1 (type P) —
FHYKP45BV1
FHYKP60BV1
FHYKP71BV1
