Additional Checks for Troubleshooting ESiEN02–01A
3–74 Part 3 – Troubleshooting
3
1
3
4
5
5.10 R3T
Temperature –
resistance
The table below is the thermistor (R3T) temperature – resistance conversion table.
Temp.
(°C)
Resist.
(k⍀)
Temp.
(°C)
Resist.
(k⍀)
Temp.
(°C)
Resist.
(k⍀)
— — 60.0 52.8 130.0 5.4
—
-6.0
-4.0
-2.0
—
1120.0
1002.5
898.6
62.0
64.0
66.0
68.0
48.9
45.3
42.0
39.0
132.0
134.0
136.0
138.0
5.4
4.8
4.6
4.3
0.0 806.5 70.0 36.3 140.0 4.1
2.0
4.0
6.0
8.0
724.8
652.2
587.6
530.1
72.0
74.0
76.0
78.0
33.7
31.4
29.2
27.2
142.0
144.0
146.0
148.0
3.9
3.7
3.5
3.3
10.0 478.8 80.0 25.4 150.0 3.2
12.0
14.0
16.0
18.0
432.9
392.0
355.3
322.4
82.0
—
—
—
23.7
—
—
—
152.0
154.0
156.0
158.0
3.0
2.9
2.7
2.6
20.0 292.9 — — 160.0 2.5
22.0
24.0
26.0
28.0
266.3
242.5
221.0
201.6
92.0
94.0
96.0
98.0
16.9
15.8
14.8
13.9
162.0
164.0
166.0
168.0
2.3
2.5
2.1
2.0
30.0 184.1 100.0 13.1 170.0 1.9
32.0
34.0
36.0
38.0
168.3
154.0
141.0
129.3
102.0
104.0
106.0
108.0
12.3
11.5
10.8
10.2
172.0
174.0
176.0
178.0
1.9
1.8
1.7
1.6
40.0 118.7 110.0 9.6 180.0 1.5
42.0
44.0
46.0
48.0
109.0
100.2
92.2
84.9
112.0
114.0
116.0
118.0
9.0
8.5
8.0
7.6
—
50.0 78.3 120.0 7.1
52.0
54.0
56.0
48.0
72.2
66.7
61.6
57.0
122.0
124.0
126.0
128.0
6.7
6.4
6.0
5.7
