ESiEN02–01A Disassembly and Maintenance: Outdoor Units
Part 5 – Disassembly and Maintenance 5–7
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
1 Front plate assy 27 Stop valve assy (liquid line)
1.1 DAIKIN name plate 27.1 Stop valve cover
1.2 R407C sticker 28 Flare nut
2 Right side plate 29 Stop valve assy (gas line)
3 Top plate 29.1 Stop valve cover
4 Discharge grille 29.2 Valve core
5 Suction grille 29.3 Blind cap
6 Bottom frame 30 Flare nut
7 Set plate for compressor 31 Service port assy
8 Service cover assy 31.1 Valve core
8.1 Wiring diagram sticker 31.2 Blind cap
9 Handle 32 Fan motor
10 Partition plate 33 Propeller fan
11 Fan motor stand 34 Fan nut
12 Compressor 35 Switch box assy
13 Compressor rubber 35.1 Switch box set plate
14 Nut 35.2 Magnetic contactor
15 Terminal cover 35.3 Magnetic switch
16 Terminal nut 35.4 Running capacitor
17 Terminal rubber 35.5 Capacitor (fan motor)
18 Compressor sound absorber 1 35.6 Thermostat
19 Compressor sound absorber 2 35.7 Surge absorber
20 Compressor sound absorber 3 35.8 Wire terminal
21 Compressor sound absorber top 35.9 Wire clamp
22 Sound absorber 35.10 Insulation strip
23 Outdoor heat exchanger assy 35.11 Noise filter assy
24 Bypass sealing plate 35.12 Capacitor fixing band
25 Cushion for heat exchanger assy 35.13 Reverse phase protector
26 Capillary tube assy 36 Overload protector
26.1 Capillary tube 1 37 Set plate for thermistor
26.2 Capillary tube 2 —
26.3 Capillary joint
26.4 Sound absorber putty
