ESiEN02–01A Disassembly and Maintenance: Outdoor Units
Part 5 – Disassembly and Maintenance 5–17
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
1 Front plate 1 32 Filter
2 Front plate 2 33 Filter
3 Assy sealing side plate 34 Fan propeller
4 Top plate assy 35 Washer
5 Bottom frame assy 36 Nut with washer
6 Fixation leg 37 Receiver
7 Partition plate assy 38 Fan motor
8 DAIKIN name plate 39 Switch box body
9 Stop valve mounting plate 40 Magnetic contactor + OC
10 Fan motor base 41 Starting relay
11 Air discharge grille 42 PCB assy
12 Air suction grille 42.1 Glass tube fuse
13 Handle 43 PCB assy
14 Compressor scroll 44 Transformer
15 Rubber cushion pre-assy 45 Air thermistor
16 Nut with washer 46 Heat exchanger thermistor
17 Bolt for compressor 47 Discharge thermistor
18 Compresser sound absorber 48 Resin PCB support
19 Heat exchanger 49 Running capacitor compressor
20 Motor valve body 50 Running capacitor compressor
21 Coil motor valve 51 Start capacitor compressor
22 Solenoid valve coil 52 Capacitor fan motor
23 Solenoid valve 53 Resistor assy
24 High-pressure switch 54 Terminal strip
25 Low-pressure switch 55 Locking card spacer
26 Charge valve 56 Compressor cable assy
26.1 Valve core (service port) 57 Thermistor fixing plate
26.2 Blinde cap (service port) 58 Thermistor mounting spring
27 Stop valve assy 59 Thermistor mounting spring
28 Stop valve assy 60 Stop valve cover
29 Service cap 61 Bottom tray assy
30 Flare nut 62 Packing case shell
31 Flare nut 63 Packing cushion assy
