ESiEN02–01A Disassembly and Maintenance: Indoor Units
Part 5 – Disassembly and Maintenance 5–35
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
1 Top plate assy 31.1 Fan top plate
2 Right plate assy 31.2 Fan housing bottom
3 Left plate assy 31.3 Fan housing top
4 Interchangeable plate 31.4 Rotor assy
5 Small bottom plate 31.4.1 Hexagon socket screw
6 Large bottom plate 31.5 Fan motor
7 Air outlet flange 31.6 Fan motor stand
8 Center stay assy 31.7 Motor fixing plate assy
9 Air filter holding plate assy 31.8 Rotor assy
10 Stay for fan top panel assy 31.8.1 Hexagon socket screw
11 Fan side blind plate assy 31.9 Shaft assy
12 Cooler side blind plate assy 31.10 Coupling
13 Pipe setting plate assy 31.11 Vibro proof rubber assy
14 Swtich box cover assy 31.12 Bearing board
15 Drain pan setting plate 31.13 Bearing fixing plate
16 Drain socket cover assy 1 32 Switch box body
17 Drain socket cover assy 2 33 Switch box fixing plate
18 Suspension bracket 34 Terminal fixing plate
19 Drain pan assy 35 Option fixing plate left
19.1 Drain socket cap 36 Option fixing plate right
20 Heat exchanger assy 37 PCB assy
20.1 Distributor with filter assy 37.1 Air thermistor
20.2 Single union joint 38 Power supply transformer
20.3 Single union joint 39 Fan motor capacitor
20.4 Flare nut 40 Terminal for remote control
20.5 Flare nut 41 Terminal for power supply
21 Air filter assy 42 Wire harness
22 Service cover assy 43 Wire harness
23 Drain pump fixing plate 44 Wire harness
24 Service cover cap assy 45 Wire harness
25 Drain pump 46 Tie wrap with clip
26 Float switch 47 Thermistor (liquid)
27 Drain hose assy 48 Thermistor fixing blade
28 Vibration absorber 49 Metal clamp
29 Plain washer 50 Drain hose
30 Fitting bolt drain pump 51 Insulation for joint (gas)
31 Fan assy 52 Insulation for joint (liquid)
