ESiEN02–01A Disassembly and Maintenance: Indoor Units
Part 5 – Disassembly and Maintenance 5–39
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
1 Top plate assy 6.20 Terminal strip
2 Fan assy + fan mounting plate 6.21 Thermistor
3 Side plate right 6.22 Thermistor
4 Side plate left 6.23 Tie wrap with clip
5 Service cover assy 6.24 PCB assy
6 Switch box assy 6.25 Power supply transformer
6.1 Switch box fixing plate 6.26 Grounding wire
6.2 PCB assy power supply 6.27 Insulation switch box
6.3 Terminal fixing plate 6.28 Insulation switch box
6.4 Magnetic contactor 6.29 Insulation switch box
6.5 PCB assy 7 Hook
6.6 Switch box body 8 Filter cover
6.7 Option fixing plate left 9 Fixture heat exchanger right
6.8 Option fixing plate right 10 Fixture heat exchanger left
6.9 Wire harness 11 Bypass sealing plate
6.10 Wire harness 12 Heat exchanger assy
6.11 Wire harness power supply 13 Drain pan assy
6.12 Wire harness power supply 14 Bottom plate assy
6.14 Wire harness 15 Air filter
6.15 Wire harness 16 Pipe fixing plate
6.16 Wire harness 17 Clamp
6.17 Wire harness 18 Clamp
6.18 PCB assy 19 Thermistor (fixing)
6.19 Locking guard spacer —
