ESiEN02–01A Disassembly and Maintenance: Indoor Units
Part 5 – Disassembly and Maintenance 5–47
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
1 Top plate 22.6 Fan motor
2 Partition plate drain pump 22.7 Motor base
3 Side plate fan chamber 22.8 Fan shaft
4 Front plate assy 22.9 Coupling
5 Wiring cover 22.10 Fan bearing
6 Blind plate ducting hole 23 Swtich box without devices
7 Drain pan holder 24 Cover switch box
8 Blind cover 25 Cover switch box
9 Cover piping hole 26 Printed circuit (control unit)
10 Suspend metal 26.1 Air thermistor
11 Suspend metal 26.2 Thermistor
12 Drain pan assy 27 Locking guard spacer
13 Drain hose 28 Transformer
14 Drain pump 29 Running capacitor
15 Buffer rubber drain pump 30 Terminal block
16 Set plate drain pump 31 Fuse holder
17 Float switch 32 Fuse control circuit
18 Fitting metal decoration panel 33 Remote control
19 Fitting metal decoration panel 33.1 Bottom case remote control
20 Fitting metal decoration panel 33.2 Lead wire remote control
21 Evaporator 34 Drain hose
21.1 Union joint (liquid line) 35 Hose band
21.2 Union joint (gas line) 36 Hose band
21.3 Filter 37 Drain pipe
22 Fan assy with motor 38 Insulation tube
22.1 Top plate fan assy 39 Insulation tube
22.2 Fan housing 40 Hook remote control
22.3 Fan housing 41 Staple
22.4 Clamp metal fan motor 42 Blind air discharge
22.5 Fan motor 43 Blind air discharge
