ESiEN02–01A Disassembly and Maintenance: Indoor Units
Part 5 – Disassembly and Maintenance 5–51
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component No. Component
B1 Heat exchanger assy F3 Side plate assy swing unit F12 Decorative frame air dis-
charge
B1.1 Distributor F3.1 Side plate F13 Decorative frame air dis-
charge
B1.2 Union joint (gas line) F3.2 Air swing unit F14 Decorative frame air dis-
charge
B1.3 Union joint (liquid line) F3.2.1 Air swing motor F15 Horizontal vane air dis-
charge
B1.4 Flare nut F3.2.2 Limit switch F16 Horizontal vane air dis-
charge
B1.5 Flare nut F3.2.3 Bearing assy (right) F17 Blind plate pipng hole
C1 Rotor assy F3.2.4 Bearing assy (left) F18 Partition plate evaporator
C2 Lock nut fan rotor F3.2.5 Joint F19 Blind plate heat exchanger
E1 Electric components assy F3.2.6 Air swing motor base F20 Fitting plate evaporator
E2 Switch box F3.2.7 Cover air swing motor F21 Retainer refrigerant piping
E3 Set plate control devices F3.2.8 Cam air swing F22 Cover inspection hole
E4 PCB assy F4 Side plate assy F23 Bell mouth
E4.1 Printed circuit (control) F4.1 Side plate F24 Drain hose assy
E4.1.1 Air thermistor F4.2 Bearing assy (right) F25 Drain pan assy
E4.2 Capacity setting adapter F4.3 Bearing assy (left) F25.1 Drain plug
E5 Printed circuit (power unit) F5 Hook metal refrigerant pip-
ing
F26 Heat insulator (internal)
E5.1 Fuse F6 Hook metal F27 Air adjust plate
E6 Terminal block F7 Hook metal F28 Retainer lead wire
E7 Capacitor F8 Air suction grille assy F29 Retainer thermistor
E8 Terminal block F8.1 Air suction grille F30 Set bolt fan motor
E9 Wire harness (transmission) F8.2 Reinforcement plate F31 Vibration isolator fan motor
E10 Wire harness (power unit) F8.3 Air dilection lever assy F32 Set plate drain pump
E11 Wire harness (power unit) F8.3.1 Lever air suction grille F32.1 Set base drain pump
E12 Wire harness (PCB termi-
nal)
F8.3.2 Spring air suction grille F32.2 Float switch
E13 Grounding wire F8.4 Air direction lever assy F32.3 Buffer rubber drain pump
E14 Wire clip F8.5 Air filter F34 Set bolt fan motor
E15 Wire clip F8.6 Reinforcement metal grille F35 Plain washer
E16 Edge saddle F8.7 DAIKIN name plate K2 Insulation cover (liquid line)
E17 Cover switch box F8.8 Reinforcement plate K3 Insulation tube (gas line)
E18 Housing power unit F9 Corner cover assy K4 Hose band
E19 Wire harness (fan motor) F9.1 Corner cover K5 Drain hose
E20 Drain pump F9.2 Corner cover K6 Drain pipe joint
E22 Heat exchanger thermistor F10 Corner cover refrigerant
piping
K7 Lead wire remote control
E23 Fan motor F10.1 Corner cover upper K8 Sealer drain hose
E24 Grounding wire F10.2 Corner cover lower K9 Staple
F1 Top plate F10.3 Internal corner cover K10 Pan head wood screw
F2 Side plate assy F10.4 Internal corner cover K11 Shelter air discharge grille
F2.1 Side plate F10.5 Tapping screw K12 Lock plate insulator
F2.2 Joint assy F11 Decorative frame air dis-
charge
K13 Lock plate insulator
