8 | Configuration
Installer reference guide
142
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
Parameter Setting Range Default
settings
Description
Installation type 0~3 0 ▪ 0=Combi
▪ 1=Heating only + external
domestic hot water tank
▪ 2=Domestic hot water only
(no heating system required)
▪ 3=Heating only
It is recommended not to
modify this setting.
Space heating pump
continuous
0~3 0 ▪ 0=Post purge period only
▪ 1=Pump continuously active
▪ 2=Pump continuously active
with MIT switch
▪ 3=Pump on with external
switch
This setting has no effect.
Maximum space heating
power set
~85% 70% Maximum power in heating.
This is a percentage of the
maximum set in parameter .
We strongly recommend not
modifying this setting.
. Maximum capacity space
heating pump
— 80 There is no space heating
pump in the gas boiler.
Changing this setting has no
effect.
Maximum domestic hot water
power set
(not applicable for
Switzerland)
~100% 100% Maximum power in instant
domestic hot water. This is a
percentage of the maximum
set in parameter . Because of
the 2-digit display, the highest
displayable value is 99. It is
however possible to set this
parameter to 100% (default
setting). We strongly
recommend not modifying this
setting.
Minimum supply temperature
of the heat curve
10°C~25°C 15°C Do NOT modify this setting on
the boiler. Use the user
interface instead.
. Maximum supply temperature
of the heat curve
30°C~90°C 90°C Do NOT modify this setting on
the boiler. Use the user
interface instead.
Minimum outside
temperature of the heat curve
–30°C~10°C –7°C Do NOT modify this setting on
the boiler. Use the user
interface instead.
