Daikin CHYHBH08AFV32 [25/220] About the units and options
![Daikin CHYHBH08AFV32 [25/220] About the units and options](/views2/1798393/page25/bg19.png)
5 | About the units and options
Installer reference guide
25
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
5 About the units and options
5.1 Overview: About the units and options
This chapter contains information about:
▪ Identifying the indoor unit
▪ Identifying the gas boiler
▪ Combining outdoor and indoor units
▪ Combining the indoor unit with options
▪ Combining the gas boiler with options
5.2 Identification
NOTICE
When installing or servicing several units at the same time, make sure NOT to switch
the service panels between different models.
5.2.1 Identification label: Indoor unit
Location
Model identification
Example: CHYHBH05AAV3
Code Description
C Residential multi compatible model
HY Hybrid indoor unit
HBH Hydrobox heating only
05 Capacity class
AA Model series
V3 Power supply
