Daikin CHYHBH08AFV32 [23/220] About the box

4 | About the box

Installer reference guide

CHYHBH05+08AF + EHYKOMB33A

Daikin Altherma R Hybrid

4P471761-1E – 2020.10

WARNING

Tear apart and throw away plastic packaging bags so that nobody, especially

children, can play with them. Possible risk: suffocation.

4.3.2 To remove the accessories from the gas boiler

1 Remove the accessories.

a b c

a Mounting strip

b Condensate trap
