7 | Installation
Installer reference guide
94
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
Special remark regarding C
43
: See the table below for the minimum diameters of
the combined gas exhaust/air intake system.
Number of
units
Concentric Dual pipe
Gas exhaust Air intake Gas exhaust Air intake
2 161 302 161 255
3 172 322 172 272
4 183 343 183 290
5 195 366 195 309
6 206 386 206 326
7 217 407 217 344
8 229 429 229 363
9 240 449 240 380
10 251 470 251 398
11 263 493 263 416
12 274 513 274 434
13 286 536 286 453
14 297 556 297 470
15 308 577 308 488
16 320 599 320 507
17 331 620 331 524
18 342 641 342 541
19 354 663 354 560
20 365 683 365 578
Special remark regarding C
93
: The minimum inner dimensions of the chimney have
to be 200×200mm.
INFORMATION
In case of a C
13
type flue gas system, a flue gas flap valve (EKFGF1A) is recommended.
7.12.5 Applicable materials
Materials for the installation of the gas exhaust and/or air intake MUST be bought
according to the table below.
D BG BA HR HU SK SICZ ES PT PL GR CY IE TR MT LTLT LV UK FR B
Daikin
Daikin
Daikin
Daikin
Daikin
Daikin
(b) (a)(a) (a) (b)
C
C
C
C
93
C
C
C
83
63
53
43
33
13
IT CH
AT
(b)
a Gas exhaust/air intake parts can be bought from a third party. All parts purchased
from an external supplier MUST comply with EN14471.
