5 | About the units and options
Installer reference guide
34
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
Accessories Part number Description
EKFGP6341 Extension Flex PP80 L=25m
EKFGP6342 Extension Flex PP80 L=50m
EKFGP6324 Connector-flex-flex PP80
EKFGP6333 Spacer PP80-100
EKFGP4481 Fixation Ø100
EKFGV1101 Chimney connection 60/10 airintake
Dn.80 C83
EKFGV1102 Connection set 60/10-60 Flue/Air
intake Dn.80 C53
EKFGW4001 ExtensionPBM-Air 80×500
EKFGW4002 ExtensionPBM-Air 80×1000
EKFGW4004 ExtensionPBM-Air 80×2000
EKFGW4085 ElbowPPBM-Air8090°
EKFGW4086 ElbowPPBM-Air8045°
EKGFP1289 ElbowPP/GALV 60/100 50°
EKGFP1299 Kit horizontal low profile PP/GLV
60/100 (UK only)
INFORMATION
For extra configuration options regarding the flue gas system, visit http://
fluegas.daikin.eu/.
INFORMATION
For the installation of the flue and air supply duct material, see the manual included
with the materials. Contact the manufacturer of the relevant flue and air supply duct
materials for extensive technical information and specific assembly instructions.
