Daikin CHYHBH08AFV32 [77/220] Installation

7 | Installation

Installer reference guide

CHYHBH05+08AF + EHYKOMB33A

Daikin Altherma R Hybrid

4P471761-1E – 2020.10

Wire type Installation method

Single-core wire

c b

AA´

A´

a Curled single-core wire

b Screw

c Flat washer

Stranded conductor wire

with round crimp-style

terminal

c b ba c

a Terminal

b Screw

c Flat washer

Allowed

NOT allowed

7.10.4 To connect the electrical wiring to the indoor unit

It is recommended to install all electrical wiring to the hydro box before installing

the boiler.

1 Wiring should enter the unit from the bottom.

2 Routing of the wiring inside the unit should be as follows:
