Daikin CHYHBH08AFV32 [22/220] About the box

4 | About the box

Installer reference guide

CHYHBH05+08AF + EHYKOMB33A

Daikin Altherma R Hybrid

4P471761-1E – 2020.10

a b c d e

f g h

a General safety precautions

b Addendum book for optional equipment

c Indoor unit installation manual

d Operation manual

e Quick installation guide

f Connection pieces for gas boiler

g Boiler communication cable

h Reducer accessory set

4.3 Gas boiler

4.3.1 To unpack the gas boiler

Before unpacking, move the gas boiler as close as possible to its installation

position.
