Daikin CHYHBH08AFV32 [37/220] Preparation

6 | Preparation

Installer reference guide

CHYHBH05+08AF + EHYKOMB33A

Daikin Altherma R Hybrid

4P471761-1E – 2020.10

H>500

300

10 350 500

(mm)

H Distance measured from the floor to the bottom of the casing of the gas boiler

(minimum 500mm, and in case of a valve mounting kit: 800mm).

h Distance measured from the floor to the flare nut of the refrigerant piping.
