15 | Technical data
Installer reference guide
206
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
EHYKOMB33AA*
Efficiency space heating (net calorific value
80/60) η
100
98.7%
Efficiency space heating (net calorific value
37/30 - 30%) η
30
108.3%
Operation range 30~90°C
Pressure drop See "15.7ESP curve: Indoor
unit"[4204].
Domestic hot water (not applicable for Switzerland)
Nominal load domestic hot water Q
nw
(H
s
) 8.4~36.3kW
Nominal load domestic hot water Q
nw
(H
i
) 7.6~32.7kW
Maximum water pressure PMW 8bar
Efficiency domestic hot water (net calorific
value)
105%
Operation range 40~65°C
Domestic hot water flow rate (setpoint 60°C) 9l/min
Domestic hot water flow rate (setpoint 40°C) 15l/min
Domestic water threshold 2l/min.
Effective unit wait time <1sec
Domestic water side pressure difference See "9.3.1Flow resistance
graph for appliance domestic
hot water circuit"[4151].
Casing
Colour White – RAL9010
Material Pre-coated sheet metal
Dimensions
Packing (H×W×D) 900×500×300mm
Unit (H×W×D) 710×450×240mm
Machine net weight 36kg
Packed machine weight 37kg
Packing material Carton/PP (straps)
Packing material (weight) 1kg
Boiler water volume 4l
Main components
Water side heat exchanger Aluminium, copper
Space heating water circuit
Space heating piping connections Ø22mm
Piping material Cu
Safety valve See indoor unit manual
Manometer Digital
