5 | About the units and options
Installer reference guide
31
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
Accessories Part number Description
EKFGP4667 Meas. tee with inspection panel PP/
GLV 60/100
EKFGP4631 Wall bracket Ø100
EKFGP1292 Wall terminal Kit PP/GLV 60/100
EKFGP1293 Wall terminal kit low profile PP/GLV
60/100
EKFGP1294 Plume management kit 60 (UK only)
EKFGP1295 Flue deflector 60 (UK only)
EKFGP1284 PMK elbow 60 90 (UK only)
EKFGP1285 PMK elbow 60 45° (2pieces) (UK only)
EKFGP1286 PMK extension 60 L=1000 includes
bracket (UK only)
EKFGW5333 Weather slate flat aluminium 80/125
EKFGW6359 Wall terminal kit PP/GLV 80/125
EKFGP4801 Extension PP/GLV 80/125×500mm
EKFGP4802 Extension PP/GLV 80/125×1000mm
EKFGP4814 Elbow PP/GLV 80/125 30°
EKFGP4811 Elbow PP/ALU 80/125 45°
EKFGP4810 Elbow PP/ALU 80/125 90°
EKFGP4820 Inspection elbow Plus PP/ALU 80/125
90° EPDM
EKFGP6864 Roof Terminal PP/GLV 80/125 AR300
RAL9011
EKFGT6300 Weather slate steep Pb/GLV 80/125
18°-22°
