Daikin CHYHBH08AFV32 [33/220] About the units and options
![Daikin CHYHBH08AFV32 [33/220] About the units and options](/views2/1798393/page33/bg21.png)
5 | About the units and options
Installer reference guide
33
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
Accessories Part number Description
EKFGP6349 Extension flex PP100 L=15m
EKFGP6347 Extension flex PP100 L=25m
EKFGP6325 Connector flex-flex PP100
EKFGP5197 Chimney top PP 130 with included flue
pipe
EKFGS0252 Adapter flex-fixed PP130
EKFGP6353 Support bracket top inox Ø130
EKFGS0250 Extension flex PP130 L=130m
EKFGP6366 Connector flex-flex PP130
EKFGP1856 Flex kit PPØ60-80
EKFGP4678 Chimney connection 60/100
EKFGP2520 Flex kit PP Ø80
EKFGP4828 Chimney connection 80/125
EKFGP6340 Extension Flex PP80 L=10m
EKFGP6344 Extension Flex PP80 L=15m
