5 | About the units and options
Installer reference guide
32
CHYHBH05+08AF + EHYKOMB33A
Daikin Altherma R Hybrid
4P471761-1E – 2020.10
Accessories Part number Description
EKFGT6301 Weather slate steep Pb/GLV 80/125
23°-27°
EKFGP7909 Weather slate steep PF 80/125
25°-45° RAL9011
EKFGT6305 Weather slate steep Pb/GLV 80/125
43°-47°
EKFGT6306 Weather slate steep Pb/GLV 80/125
48°-52°
EKFGT6307 Weather slate steep Pb/GLV 80/125
53°-57°
EKFGP1297 Weather slate flat aluminium 80/125
0°-15°
EKFGP6368 Tee flex 100 boiler connection set 1
EKFGP6354 Flex 100-60 + support elbow
EKFGP6215 Tee flex 130 boiler connection set 1
EKFGS0257 Flex 130-60 + support elbow
EKFGP4678 Chimney connection 60/100
EKFGP5461 Extension PP 60×500
EKFGP5497 Chimney top PP 100 with included flue
pipe
EKFGP6316 Adapter flex-fixed PP 100
EKFGP6337 Support bracket top inox Ø100
EKFGP6346 Extension flex PP100 L=10m
