room

) Maximum refrigerant charge in a room (m

max

) (kg)

H=500mm,

600mm,

700mm

H=800mm H=900mm H=1000mm H=1100mm H=1200mm H=1300mm H=1400mm H=1500mm H=1600mm H=1700mm H=1800mm

h=600mm h=700mm h=800mm h=900mm h=1000mm h=1100mm h=1200mm h=1300mm h=1400mm h=1500mm h=1600mm h=1700mm

50 2.41 2.82 3.22 3.62 4.02 4.43 4.83 5.23 5.63 6.03 6.44 6.84

INFORMATION

▪ h=The height measured from the floor to the flare nut.

▪ H=The height measured from the floor to the bottom of the casing.

▪ For intermediate H values (i.e., when H is between 2 H values from the table),

consider the value that corresponds to the lower H value from the table. If

H=950mm, consider the value that corresponds to "H=900mm".

▪ In cases where H≤600mm, h is always considered to be 600mm, as specified in

IEC60335-2-40:2013 A1 2016, clause GG2.

▪ For intermediate A

room

values (i.e., when A

room

is between 2 A

room

values from the

table), consider the lower A

room

value from the table. If A

room

=12.5m

, consider the

value that corresponds to "A

room

=12m

▪ Systems with a total refrigerant charge (m

) ≤1.842kg are NOT subjected to any

requirements to the installation room.
