GRAPHITE 58G047 [12/68] Operation settings

PREPARATION FOR OPERATION

BLADE INSTALLATION

Installation and removal of the blade is tool free.

• Lift the guard (8) (g. A).

• Pull the blade holder lever (9) upwards (g. B).

• Slide blade to the blade holder to mechanical stop (blade teeth

should face forward).

• Important! Make sure the blade is properly positioned in the

guiding roller (7).

• Set the blade holder lever (9) down and ensure the blade is

properly seated (g. C).

Use blades suitable for T-shank holder mechanism, as shown on

g. D.

DUST EXTRACTION

To improve dust extraction from processed material surface, the

jigsaw is equipped with own dust blow-o and extraction system,

which cleans the surface being cut. Dust blow-o and extraction

system is more ecient when the guard is lowered. Additionally,

dust extraction outlet (5) allows to attach an external dust extraction

system, e.g. workshop vacuum cleaner.

• Attach suction hose of the dust extraction system to the adapter

(5). Make sure the connection is tight.

OPERATION / SETTINGS

SWITCHING ON / OFF

Before connecting the jigsaw to a power supply al

ys check that

the power supply voltage matches the voltage specied on the

rating plate xed on the power tool.

Switching on – press the switch button (2) and hold in this position.

Switching o – release the switch button (2).

Locking the switch (continuous operation)

Switching on:

• Press the switch button (2) and hold in this position.

• Press the switch lock button (3) (g. E).

• Release the switch button (2).

Switching o:

• Press and release the switch button (2).

Each time the switch button (2) is pressed, the LED diode (10)

lights up to illuminate the workplace.

VOLTAGE INDICATOR

Power indicator (4) is located in the rear part of the hand grip casing,

it turns on when the power tool is connected to a mains power

supply.

CONTROL OF JIGSAW OPERATION SPEED

You can control rotational speed of the jigsaw motor by turning and

setting the work speed control wheel (1) in desired position. It allows

to adjust the power tool working speed to match characteristics of

processed material. Speed control range is 0 to 5.

The bigger the number on the wheel rim (1) (g. F), the greater the

jigsaw operation speed.

FOOTPLATE ADJUSTMENT FOR BEVEL CUTTING

Adjustable jigsaw footplate allows to make a bevel cut in the range

from 0° to 45° (to either side).

• Use the hexagonal key and loosen the footplate (6) xing screws.

• Move the footplate (6) backwards and tilt right or left (up to 45°).

• Set the footplate (6) at desired angle, move forward and tighten

the xing screws to secure it (g. G).

You can read footplate bevel angle on the angular scale located on

the footplate. Take out the hexagonal key and put it in its storage

place after adjustment is made.

CUTTING

• Put front part of the footplate (6) at on the material that you plan

to cut.

• Switch on the jigsaw and wait until it reaches its full set rotational

speed.

• Move the jigsaw slowly and guide the blade along previously set

cutting line.

• When cutting curved lines move the jigsaw very carefully.

Make a cut at a uniform rate, be careful not to overload the jigsaw.

Excessive pressure applied on the blade will suppress its movement

and will hinder cutting eciency.

When the jigsaw footplate does not rest on the processed

material with its whole surface, but is lifted above instead, there

is danger of breaking the blade.

CUTTING A HOLE IN MATERIAL

• Make a hole in processed material with 10 mm diameter.

• Put blade into the hole and start cutting from that spot.

METAL CUTTING / TYPES OF BLADES

Use appropriate blades with more teeth for cutting of metal.

Use appropriate coolant when cutting metal. Cutting metal without

any coolant leads to faster wear of blade. The below table gives the

rough choices for the blade type:

Teeth per inch

Blade

length

Application range

80 mm

Soft steel, non-ferrous

metals

Non-ferrous metals,

plastics

9 Wood, plywood.

OPERATION AND MAINTENANCE

Unplug the power cord from mains socket before commencing

any activities related to installation, adjustment, repair or

maintenance.

MAINTENANCE AND STORAGE

• Cleaning the device after each use is recommended.

• Do not use water or any other liquid for cleaning.

• Clean the device with a dry cloth or blow through with

compressed air at low pressure.

• Do not use any cleaning agents or solvents, since they may

damage plastic parts.

• Clean ventilation holes in the motor casing regularly to prevent

device overheating.

• In case of the power cord damage replace it with a cord with the

same specication. Entrust the repair to a qualied specialist or

return the tool to a service point.

• In case of excessive commutator sparking, have the technical

condition of carbon brushes of the motor checked by a qualied

person.

• Always store the tool in a dry place, beyond reach of children.

REPLACEMENT OF CARBON BRUSHES

Immediately replace worn out (shorter than 5 mm), burnt or

cracked motor carbon brushes. Always replace both carbon

brushes at a time.
