![GRAPHITE 59G324 [8/48] Translation of the original instructions finishing sander 59g324](/img/pdf.png)
GRAPHITE 59G324 [8/48] Translation of the original instructions finishing sander 59g324
![GRAPHITE 59G324 [8/48] Translation of the original instructions finishing sander 59g324](/views2/2041625/page8/bg8.png)
8
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Dust container - 1 pce
2. Abrasive paper - 2 pcs
PREPARATION FOR OPERATION
CHOOSING SANDING PAPER
Coarse-grained abrasive paper is generally used for coarse processing
of most materials, while ne-grained paper is used for nishing works.
• When the surface is not at, start the work with coarse-grained
sanding paper and continue until the surface is at.
• Next use middle-grained paper to remove traces of coarse processing.
• To nish the work use ne-grained sanding paper.
INSTALLATION OF SANDING PAPER
Disconnect the power tool from power supply.
• Select sanding paper gradation appropriate for the planned task.
• Loosen sanding paper clamps (6) (g. A).
• Fix the sanding paper on the sander backing pad (7).
• Make sure that the holes on the sanding paper (8) and the backing
pad (6) match fully (g. B).
• Bend both ends of the sanding path on the sander backing pad
edges.
• Tighten the sanding paper clamps (5) (g. C).
• Make sure the sanding paper is installed properly.
Sanding paper must fully adhere to the sander backing pad. There
must be no slack. If the paper stretches during sanding, remove the
slack. It will signicantly prolong the lifetime of the sanding paper.
DUST EXTRACTION
The sander is equipped with hook and loop attachment pad. Equipment
of the nishing sander includes dust container (5) that helps to maintain
the processed surface clean. Use properly matched, perforated sanding
paper, so the dust can reach extraction hole through the backing pad.
INSTALLATION / REMOVAL / CLEANING OF THE DUST CONTAINER
• Press the installation button (9) and slide out the dust container (5)
backwards (g. D).
• Press the cover locking buttons (11) on both sides and take o the
dust container cover (10) (g. E).
• Remove the lter (12), clean it and remove the dust from the
container (10) (g. F).
• Install all parts in reversed sequence of disassembly.
• Slide the dust container (10) fully in, until the installation button
snaps (9) (g. G).
• Pull the dust container gently to make sure it is xed securely.
It is recommended to empty the container when it is half-full.
OPERATION / SETTINGS
SWITCHING ON / OFF
The mains voltage must match the voltage on the rating plate of
the sander.
Switching on – slide the switch (3) forward to position I.
Switching o – slide the switch (3) backward to position O (g. H).
OSCILLATION SPEED CONTROL
You can control the speed of sander oscillation by turning and setting
the control wheel (1) in desired position. It allows to adjust the power
tool working speed to match characteristics of processed material.
Speed control range is 1 to 6.
The greater the number on the wheel rim (1) (g. I), the greater the
sander operation speed.
• Increase the oscillation speed by turning the wheel (1) left.
• Reduce the oscillation speed by turning the wheel (1) right.
TRANSLATION OF
THE ORIGINAL INSTRUCTIONS
FINISHING SANDER
59G324
CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL
CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
DETAILED SAFETY REGULATIONS
When sanding wood and metal surfaces coated with paints with
lead additives, harmful or toxic dust may arise. Contact or inhalation
of the dust may endanger operator’s or other persons’ health. Use
appropriate personal protection measures such as lter masks and
safety glasses. Use dust extraction system.
PRIOR TO SANDER OPERATION
• During operation hold the sander rmly with both hands.
• Make sure the sanding paper does not touch processed material prior
to switching the sander on.
• Make sure the abrasive paper is well installed and paper clamping
levers are in locking position before switching the sander on.
• Do not touch moving parts of the sander.
• After switching o, do not put away the sander until all moving parts
stop.
• Use protective mask if the dust appears during sanding. Dust, which
appears when sanding surfaces coated with lead-based paint, some
types of wood and metal, is harmful.
• Pregnant women and children should not enter the room where lead-
based paint is removed with the use of sander.
• Do not eat, drink or smoke in the room where paint with lead
compounds is removed with the sander.
• Avoid using long extension cords.
WHEN OPERATING THE SANDER
• When using the sander, always wear earmu protectors and
protection half-mask.
• Sander is not designed for wet operation.
• Make sure the switch is in the OFF position before plugging the
sander to a power supply.
• Keep the power cord away from moving parts of the sander at all
times.
• Use safety goggles or glasses when operating the sander above head.
• When operating the sander do not apply excessive pressure that
might stop the tool.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and additional
safety systems are used, nevertheless there is always a small risk of
injuries at work.
CONSTRUCTION AND USE
Finishing sander is a power tool driven by a single-phase commutator
motor. The sander does not require earth lead (insulation class II). The
nishing sander is designed for surface sanding of wood products,
polishing wood surfaces with lacquer coating, ne polishing of lacquered
metal surfaces, removal of rust or specks of lacquer before applying new
lacquer, etc. Range of use covers repair and building works, woodworking
and any work from the scope of individual, amateur activities (tinkering).
Do not use the sander for sanding surfaces that contain magnesium
or asbestos, or covered with gypsum.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
1. Wheel for oscillation control
2. Front handle
3. Switch
4. Main handle
5. Dust container
6. Sanding paper clamp
7. Pad
8. Holes for dust extraction
9. Dust container installation button
10. Dust container cover
11. Cover locking buttons
12. Filter
* Dierences may appear between the product and drawing.
