Moxa EDS-518E-4GTXSFP-T [43/116] Poe system configuration settings

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-30

PoE System Configuration Settings

PoE Power Output

Setting Description Factory Default

Enable Enables PoE power transmission to a PD Enable

Disable Disables PoE power transmission to a PD

PoE power management Mode

Setting Description Factory Default

Allocated Power If a powered device is connected that would cause the total

amount of power needed by all connected devices to exceed

the total allocated power limit, the switch will not power up the

device.

Disable

Measured Power If a powered device is connected that would cause the total

amount of power needed by all connected devices to exceed

the total measured power limit, the switch with will deny power

to the device with the lowest priority.

Enable

Deny next port when exceed

This setting only appears when “PoE power output management mode” is set to “Allocated Power.”

Setting Description Factory Default

wattage Assigns the “Total allocated power” limit for all PoE ports

combined.

240 W

Deny low priority port when exceed

This setting only appears when “PoE power output managed by” is set to “Measured Power.”

Setting Description Factory Default

wattage Assigns the “Total measured power” limit for all PoE ports

combined.

240 W

PoE Port Configuration

Power

Setting Description Factory Default

Checked Allows data and power to be transmitted through the port. Checked

Unchecked Immediately shuts off power to that port
