Moxa EDS-518E-4GTXSFP-T [47/116] Event type

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-34

Warning Type

Action Description

Trap The EDS E series will send a notification to the trap server when

event is triggered.

E-Mail The EDS E series will send a notification to the email server defined

in Email Settings.

Syslog The EDS E series will record a syslog to a syslog server defined in

Syslog Server Settings.

Relay1 The EDS E series supports digital inputs to integrate sensors. When

an event is triggered, the device will automatically activate an

alarm through the relay output.

Event Type

Port Events Description

PoE PD power on Power is being output to the PD.

PoE PD power off The PoE power output is cut off.

PoE over current When the current of the port exceeds the following limits:

802.3 af: 350 mA

802.3 at: 600 mA

High Power: 720 mA

Force: 600 mA

PoE PD Failure Check When the switch does not receive a PD response after the defined

period.

Over Measured Power Limitation When the total PD power consumption exceeds the total measured

power limit.

PoE FETBad When the MOSFET of the port is out of order (please contact Moxa

for technical service)

PoE over Temperature Check the temperature of the environment. If you cannot keep the

temperature under 75°C, contact Moxa for technical support.

PoE VEE Uvlo - VEE (PoE input voltage)

under Voltage Lockout

The voltage of the power supply has dropped below 44 VDC.

Adjust

the voltage to between 46 and 57 VDC to eliminate this issue.

Over Allocated Power Limitation When the total PD power consumption exceeds the total allo

cated

power.

NOTE

The Relay Output does not support three Event Types:

External FET has failed, PSE chip is over

temperature

, and V

(PoE input voltage) under voltage lockout.
