Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions
3-42
VLAN ID Configuration Table
Enable GVRP
Setting Description Factory Default
Checked/Unchecked Check the checkbox to enable the GVRP function.
Remove the
checkmark to disable the GVRP function.
Checked
Management VLAN ID
Setting Description Factory Default
1 to 4094 Assigns the VLAN ID to this Moxa switch. 1
Note: Some of the following settings can be modified in the Quick Setting Panel.
Port
Setting Description Factory Default
Port name Read only N/A
Type
Setting Description Factory Default
Access When this port is connected to a single device, without tags. Access
Trunk When this port is connected to another 802.1Q VLAN aware
switch.
Hybrid When this port is connected to another Access 802.1Q VLAN
aware switch or another LAN that combines tagged and/or
untagged devices and/or other switches/hubs.
ATTENTION
For comm
unication redundancy in the VLAN environment, set Redundant Port Coupling Ports and
Coupling Control Port
s to Trunk Port, since these ports act as the backbone for transmitting packets
fr
om different VLANs to different Moxa switch units.
PVID
Setting Description Factory Default
1 to 4094 Sets the default VLAN ID for untagged devices connected
to the
port.
1
Tagged VLAN
Setting Description Factory Default
1 to 4094 This field will be active only when selecting the Trunk or Hybrid
port type. Set the other VLAN ID for tagged devices that
connect to the port. Use commas to separate different VIDs.
None
Untagged VLAN
Setting Description Factory Default
VID range from 1 to
4094
This field is only active when the Hybrid port type is selected.
Set the other VLAN ID for tagged devices that connect to the
port and tags that need to be removed in egress packets. Use
commas to separate different VIDs.
None
Forbidden VLAN
Setting Description Factory Default
1 to 4094 This field is only active when Trunk or Hybrid port type is
selected
. Set the other VLAN IDs that will not be supported by
None
