Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-74

Authentication Protocol

Setting Description Factory Default

802.1X Local

(Max. of 32 users)

Select this option when setting the 802.1X Local User Database

as the authentication database.

802.1X Local

RADIUS Select this option to set an external RADIUS server as the

authentication database. The authentication mechanism is

EAP-MD5.

RADIUS, 802.1X Local Select this option to make using an external RADIUS server as

the authentication database the first priority. The

authentication mechanism is EAP-MD5. The second priority is

to set the 802.1X Local User Database as the authentication

database.

Re-Auth (Global)

Setting Description Factory Default

Enable/Disable Select enable to require re-authentication of the client after a

preset time period of no activity has elapsed.

Enable

Re-Auth Period (sec)

Setting Description Factory Default

60 to 65535 Sets the Re-Auth period 3600

Enable 802.1X

Setting Description Factory Default

Select/Deselect Select the checkbox under the 802.1X column to enable IEEE

802.1X for one or more ports. All end stations must enter

usernames and passwords before access to these ports is

allowed.

Deselect

Re-Auth

Setting Description Factory Default

Select/Deselect Select enable to require re-authentication of the client by port

Deselect
