Moxa EDS-518E-4GTXSFP-T [65/116] Igmp snooping setting

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-52

IGMP Snooping

IGMP Snooping provides the ability to prune multicast traffic so that it travels only to those end destinations

that require that traffic, thereby reducing the amount of traffic on the Ethernet LAN.

NOTE

IGMP Snooping will be disabled when Port

-Based VLAN is enabed.

IGMP Snooping Setting

Enable IGMP Snooping (Global)

Setting Description Factory Default

Enable/Disable Select the Enable IGMP Snooping checkbox near the top of the

window to enable the IGMP Snooping function globally.

Disabled

Query Interval (sec)

Setting Description Factory Default

Numerical value, input

by the user

Sets the query interval of the Querier function globally. Valid

settings are from 20 to 600 seconds.

125 seconds

Enable Multicast Fast Forwarding Mode

Setting Description Factory Default

Enable/Disable Select the Enable Multicast Fast Forwarding Mode checkbox

achieve fast multicast forwarding path re-learning while the

ring redundant network is down.

Note: Turbo Ring V2 or Turbo Chain must be enabled.

Disabled

Enable IGMP Snooping

Setting Description Factory Default

Enable/Disable Enables or disables the IGMP Snooping function on that

particular VLAN.

Enabled if IGMP

Snooping is enabled

globally
