Moxa EDS-518E-4GTXSFP-T [58/116] Port settings

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-45

Port

Port Settings

Port settings are included to give the user control over port access, port transmission speed, flow control, and

port type (MDI or MDIX).

Enable

Setting Description Factory Default

Checked Allows data transmission through the port. Checked

Unchecked Immediately shuts off port access.

Media Type

Setting Description Factory Default

Media type Displays the media type for each module’s port N/A

Description

Setting Description Factory Default

Max. 63 characters Specifies an alias for the port to help administrators

differentiate between different ports. Example: PLC 1

None

Speed

Setting Description Factory Default

Auto Allows the port to use the IEEE 802.3u protocol to negotiate

with connected devices. The port and connected devices will

determine the best speed for that connection.

Auto

1G-Full Choose one of these fixed speed options if the connected

Ethernet device has trouble auto-negotiating for line speed.

100M-Full

100M-Half

10M-Full

10M-Half
