3-66

Rate Limiting: Port Disable

Setting Description Factory Default

Port disable duration

(1-65535 seconds

When the ingress packets exceed the ingress rate limit, the

port will be disabled for a certain period.

30 seconds

Ingress (frame per

second)

Select the ingress rate (fps) limit for all packets from the

following options: Not Limited, 4464, 7441, 14881, 22322,

37203, 52084, 74405

Unlimited

NOTE

The

Port Disable function of Rate Limiting is for multicast packets and broadcast packets.

Type 4

For Type 4, the Control Mode setting on the Rate Limiting page can be set to Normal or Port Disable.

Control Mode

Setting Description Factory Default

Normal Set the max. ingress rate limit for different packet types 30 seconds

Port Disable When the ingress multicast and broadcast packets exceed the

ingress rate limit, the port will be disabled for a

certain period.

During this period, all packets from this port will be discarded.

Unlimited
