Type 3

For Type 3, the Action setting on the Rate Limiting page can be set to Drop Packet or Port Disable.

Action

Setting Description Factory Default

Drop Packet Set the max. ingress/egress rate limit for ingress/egress

packets

Drop Packet

Port Disable When the ingress packets exceed the ingress rate limit, the

port will be

disabled for a certain period. During this period, all

packets from this port will be discarded.

Rate Limiting: Drop Packet

Setting Description Factory Default

Ingress rate (% of

max. throughput)

Select the ingress rate limit (% of max. throughput) for all

packets from the following options: Not Limited, 3%, 5%, 10%,

15%, 25%, 35%, 50%, 65%, 85%

Unlimited

Egress rate (% of

max. throughput)

Select the egress rate limit (% of max. throughput) for all

packets from the following options: Not Limited, 3%, 5%, 10%,

15%, 25%, 35%, 50%, 65%, 85%

Unlimited

NOTE

The

Drop Packet function of Rate Limiting is for multicast packets and broadcast packets.
