Moxa EDS-518E-4GTXSFP-T [61/116] Link swap fast recovery

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-48

Trunk Group (maximum of 4 trunk groups)

Setting Description Factory Default

Trk1, Trk2, Trk3, Trk4

(depends on switching

chip capability; some

Moxa switches only

support 3 trunk

groups)

Specifies the current trunk group. Trk1

The EDS 400A series does not support Port Trunking. The number of Trunk Groups for other models are listed

in the following table:

No. of Trunk Groups Model

2 EDS-505A, EDS-P506A-4PoE, EDS-516A

3 EDS-518A

4 For other models

Trunk Type

Setting Description Factory Default

Static Selects Moxa’s static trunking protocol. Static

LACP Selects LACP (IEEE 802.3ad, Link Aggregation Control

Protocol).

Static

Trunking Status

The Trunking Status table shows the Trunk Group configuration status.

Link-Swap Fast Recovery

The Link-Swap Fast Recovery function, which is enabled by default, allows the Moxa switch to return to normal

operation extremely quickly after devices are unplugged and then re-plugged into different ports. The recovery

time is on the order of a few milliseconds (compare this with standard commercial switches for which the

recovery time could be on the order of several minutes). To disable the Link-Swap Fast Recovery function, or

to re-enable the function after it has already been disabled, access either the Console utility’s Link-Swap

recovery page, or the Web Browser interface’s Link-Swap fast recovery page, as shown below.

Link-Swap-Fast-Recovery

Setting Description Factory Default

Enable/Disable Select the checkbox to enable the Link-Swap-Fast-Recovery

function

Enable
