Port Security

Moxa switches provide a Port Security function that lets packets with allowed MAC Addresses access the

switch’s ports. Two Port Security modes are supported: Static Port Lock and MAC Address Sticky.

Static Port Lock: Allows users to configure specific MAC addresses that are allowed to access the port.

MAC Address Sticky: Allows users to configure the maximum number of MAC addresses (the Limit) that a

port can “learn.” Users can configure what action should be taken (under Violation Port Disable) when a new

MAC address tries to access a port after the maximum number of MAC addresses have already been learned.

The total number of allowed MAC addresses cannot exceed 1024.

Port Security Mode

Mode

Setting Description Factory Default

Static Port Lock The switch will block unauthorized MAC addresses and allow

access to packets with a MAC address defined in the Static

Unicast MAC Address Table.

None

MAC Address Sticky If Limit is set to n, the switch will learn the first n MAC

addresses that access the port, and automatically store

them in

the MAC Address Control Table.

Limit (only active for MAC Address Sticky)

Setting Description Factory Default

1 to 1024 The maximum number of learned MAC addresses allowed for

that port.
