Moxa EDS-518E-4GTXSFP-T [68/116] Multicast filtering behavior

Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-55

GMRP

GMRP is a MAC-based multicast management protocol, whereas IGMP is IP-based. GMRP provides a

mechanism that allows bridges and end stations to register or un-register Group membership information

dynamically.

Enable GMRP

Setting Description Factory Default

Select/Deselect Select the appropriate checkboxes to define which ports

are to

be GMRP enabled.

None

GMRP Status

The Moxa switch displays the current active GMRP groups that were detected.

MAC Address: The Multicast MAC address

Static Port: This multicast address is defined by static multicast

Learned Port: This multicast address is learned by GMRP

Multicast Filtering Behavior

Multicast Filtering Behavior supports two options: Forward Unknown and Filter Unknown.

Note: Only supported by the EDS-518E, EDS-528E, IKS-6726A, IKS-6728A, IKS-6728A-8PoE,IKS-G6524A,

IKS-G6824A, ICS-G7526A, ICS-G7826A, ICS-G7528A, ICS-G7828A, ICS-G7748A, ICS-G7848A, ICS-G7750A,

ICS-G7850A, ICS-G7752A, and ICS-G7852A Series.

Multicast Filtering Behavior

Setting Description Factory Default

Forward Unknown Allows the switch to forward all unknown Multicast streams Forward Unknown

Filter Unknown Allows the switch to drop all unknown Multicast steams
