PoE Timetabling

Powered devices usually do not need to be running 24

hours a day, 7 days a week.

The PoE Ethernet switch

provides a PoE

timetabling mechanism that lets users

economize the system

’s power burden by setting a

flexible working schedule for each PoE port.

Port

Setting Description Factory Default

Port Select which port you would like to configure. Port 1

Enable

Setting Description Factory Default

Checked Enables the PoE function of the port for the defined time

period.

Unchecked

Unchecked Enables the PoE function of the port all the time.

MON, TUE, WED, THU, FRI, SAT, SUN

Setting Description Factory Default

Checked Select those days on which you would like the port to be

enabled (you will then be able to modify the StartTime and

EndTime)

Disable

Unchecked The port will not provide PoE power on days that are not check

marked.

Start/End Time

Setting Description Factory Default

Configured time

period

Enter the hour of the day the configuration will be enabled,

and the hour of the day the configuration will be disabled.

0 to 24

PoE Warning Event Settings

Since industrial Ethernet devices are often located at the endpoints of a system, these devices do not always

know what is happening elsewhere on the network. This means that a PoE port connected to a PD must provide

system administrators with real-time alarm messages. Even when control engineers are out of the control room

for an extended period of time, they can still be informed of the status of the PD almost instantaneously when

exceptions occur. The PoE Ethernet switch supports different methods for warning engineers automatically,

including SNMP trap, email, and relay output. It also supports two digital inputs to integrate sensors into your

system to automate alarms using email and relay output. The PoE warning event settings are on the System

Event Settings page.
