Managed Ethernet Switch (UI_2.0_FW_5.x) Featured Functions

3-31

Output Mode

Setting Description Factory Default

802.3 af/at Auto Power transmission follows the IEEE 802.3 af/at protocols.

The

acceptable PD resistance range is 17 kΩ to 29 kΩ.

802.3 af/at Auto

High Power Provides a higher power output to the PD. The acceptable PD

resistance range is 17 kΩ to 29 kΩ, and the power allocation of

the port is automatically set to 36 W.

Force Provides power output to non-802.3 af/at PDs. The acceptable

PD resistance range is over 2.4 kΩ, and the range of power

allocation is 0 to 36 W.

Power Allocation

Setting Description Factory Default

0 to 36 When the Output Mode is set to Force, the Power Allocation

can be set from 0 to 36 W.

Legacy PD Detection

The PoE Ethernet Switch provides a Legacy PD Detection function. When the capacitance of the PD is higher

than 2.7 μF, checking the Legacy PD Detection checkbox enables the system to output power to the PD. In

this case, it will take 10 to 15 seconds for PoE power to be output through this port after the switch is turned

on.

Setting Description Factory Default

Checked Enables legacy PD detection Unchecked

Unchecked Disables legacy PD detection

Power Priority

Use Power Priority when managing PoE power with measured power mode. The smaller the number, the

higher the priority. You may set the same priority for different PoE ports, but if you configure two ports with the

same priority, then the port with the lower port number has the higher priority. The setting can range from 1

up to the total number of ports. When the PoE measured power exceeds the assigned limit, the switch will

disable the PoE port with the lowest priority.

Setting Description Factory Default

1 to “number of PoE

ports”

The smaller the number, the higher the PoE port priority. When

the PoE measured power exceeds the assigned limit, the switch

will disable the PoE port with the lowest priority.

The PoE port index

number
