9
User’s manual
EN
TECHNICAL DATA
Description
Model
L50BEU L50DEU L50BUS L50DUS L50EEU
Maximum recommended surface that can be mowed
Each daily working
cycle
m2
(sq
ft)
400 (4300 sq ft)
800
(8600 sq ft)
Characteristics
Size (W x H x D)
mm
(in.)
409 x 199 x 335
(16,10 x 7,83 x 13,19 in)
409 x 220 x 335
(
16,10 x 8,65 x 13,19 in
)
409 x 226 x 335
(16,10 x 8,90 x
13,19 in)
Robot weight (inc.
battery)
kg 7,9 8,2 10,3 10,6 8,0
Cutting height
(Min-Max)
mm
(in.)
34-40
(1,34-1,58 in)
48-72
(1,88-2,84 in)
34-40
(1,34-1,58 in)
4-pronged blade
diameter
mm
(in.)
250 (9,84)
Drive system 4WD
Electric motors V cc (25,2V)
Cutting blade speed RPM 4000 Cut 3000 Maintenance
Ground speed
Me-
ters/
minute
18 (59,00 ft.)
Suggested
maximum slope
%
50%. Allowable, based on the lawn conditions and accessories
installed.
40%. Maximum recommended, in conditions of a trimmed lawn.
30%. Next to the outside edge or guide wire.
Ambient working
temperature
-10°(14 F.) (Min) +42° (107 F.) (Max)
Measured sound
output
dB(A) 72(Max) - 65(Lawn maintenance)
Water protection
class
IP IP21
Electric features
Charger (for lithium
batteries)
Meanwell system Certi cate No. E307078
Classe 2 (Vin 90 - 264Vac)
AC current (typ.) 1.2A/115Vac 0.7A/230Vac
Input Frequency range 47 - 63Hz
Battery type and charger
Rechargeable Li-Ion
battery
V-A 25,2V – 6,9Ah
25,2V -
2,3Ah
Charger V-A 29,3 Vcc - 2,0 Ah
Minimum rechar-
ging time and
method
3:00 - manual
1:30 -
automatic
