User’s manual

SLOPES

Check that all the areas of the lawn do not exceed the admissible slopes (see “Technical Speci -

cations”, page 9).

Areas with steeper slopes or that are incompatible with the correct functioning of the robot (see

following points) cannot be mowed. Steeper slopes must be delimited.

Important

The sensors of the robot can detect slopes greater than the robot can manage.

The direction is reversed in order to prevent the robot from tipping over or

malfunctioning. In addition, as a further protection, it is necessary to delimit the

areas, which have slopes that cannot be managed.

It is recommended to test the robot when using for the  rst time on slopes that

are at the limit of the speci cations.

1 m.

+ 50%

included between 0° and +27°

Greater than 1 m. / 39,3 inc.

UPWARD SLOPE

The robot can tackle height differences with a slope

of up to 40% provided that they gradually slope

down over a distance of more than one metre.

1 m.

-50%

DOWNWARD SLOPE

included between 0° and -27°

Greater than 1 m. / 39,3 inc.
