ACH550-02 User's Manual
126 Application macros and wiring
14. Hand control
This application macro is intended to be used when
commissioning with Spin the Motor assistant where all
analogue and digital inputs are disabled by default.
The drive is started with the HAND key and giving the speed
reference with the arrow keys.
Note: Starting in the AUTO mode requires configuring the I/O
with parameters or the assistant or selecting another macro
(recommended).
