Parameter listing and descriptions 269
ACH550-02 User's Manual
3626 TIMER 1 SRC 0…31
Collects all wanted timers to a timed function.
0 =
NOT SEL – No timers have been selected.
1 =
P1 – Time Period 1 selected in the timer.
2 =
P2 – Time Period 2 selected in the timer.
3 =
P1+P2 – Time Periods 1 and 2 selected in the timer.
4 =
P3 – Time Period 3 selected in the timer.
5 =
P1+P3 – Time Periods 1 and 3 selected in the timer.
6 =
P2+P3 – Time Periods 2 and 3 selected in the timer.
7 =
P1+P2+P3 – Time Periods 1, 2 and 3 selected in the timer.
8 =
P4 – Time Period 4 selected in the timer.
9 =
P1+P4 – Time Periods 1 and 4 selected in the timer.
10 =
P2+P4 – Time Periods 2 and 4 selected in the timer.
11 =
P1+P2+P4 – Time Periods 1, 2 and 4 selected in the timer.
12 =
P3+P4 – Time Periods 3 and 4 selected in the timer.
13 =
P1+P3+P4 – Time Periods 1, 3 and 4 selected in the timer.
14 =
P2+P3+P4 – Time Periods 2, 3 and 4 selected in the timer.
15 =
P1+P2+P3+P4 – Time Periods 1, 2, 3 and 4 selected in the timer.
16 =
BOOST – Boost (B) selected in the timer.
17 =
P1+B – Time Period 1 and Boost selected in the timer.
18 =
P2+B – Time Period 2 and Boost selected in the timer.
19 =
P1+P2+B – Time Periods 1 and 2 and Boost selected in the timer.
20 =
P3+B – Time Period 3 and Boost selected in the timer.
21 =
P1+P3+B – Time Periods 1 and 3 and Boost selected in the timer.
22 =
P2+P3+B – Time Periods 2 and 3 and Boost selected in the timer.
23 =
P1+P2+P3+B – Time Periods 1, 2 and 3 and Boost selected in the
timer.
24 =
P4+B – Time Period 4 and Boost selected in the timer.
25 =
P1+P4+B – Time Periods 1 and 4 and Boost selected in the timer.
26 =
P2+P4+B – Time Periods 2 and 4 and Boost selected in the timer.
27 =
P1+P2+P4+B – Time Periods 1, 2 and 4 and Boost selected in the
timer.
28 =
P3+P4+B – Time Periods 3 and 4 and Boost selected in the timer.
29 =
P1+P3+P4+B – Time Periods 1, 3 and 4 and Boost selected in the
timer.
30 =
P2+P3+P4+B – Time Periods 2, 3 and 4 and Boost selected in the
timer.
31 =
P1+2+3+4+B – Time Periods 1, 2, 3 and 4 and Boost selected in
the timer.
3627 TIMER 2 SRC
• See parameter 3626.
3628 TIMER 3 SRC
• See parameter 3626.
3629 TIMER 4 SRC
• See parameter 3626.
