154 Serial communications
ACH550-02 User's Manual
5133 FBA APPL FW REV 0…0xFFFF
Contains the revision of the module’s application program. Format is
xyz, where:
• x = major revision number
• y = minor revision number
• z = correction number.
Example: 107 = revision 1.07
Code Description Range
