Diagnostics and maintenance 387
ACH550-02 User's Manual
Maintenance intervals
WARNING! Read the safety instructions in chapter Contents of
this manual, page 6 before performing any maintenance on the
equipment. Ignoring the safety instructions can cause injury or
death.
If installed in an appropriate environment, the drive requires very
little maintenance. The table lists the routine maintenance
intervals recommended by ABB.
Consult your local ABB Service representative for more details
on the maintenance. On the Internet, go to
http://www.abb.com/drives
and select Drive Services –
Maintenance and Field Services.
Maintenance Interval Instruction
Heatsink
temperature check
and cleaning
Depends on the
dustiness of the
environment
(6…12 months)
See Heatsink on
page 389.
Main cooling fan
replacement
Every six years See Main fan
replacement on
page 389.
Capacitor
reforming
Every year when
stored
See Reforming on
page 391.
Capacitor
replacement
Every nine to
twelve years
depending on the
ambient
temperature and
duty cycle
See Replacement
on page 391.
HVAC control panel
battery change
Every ten years See Control panel
(operator keypad)
on page 393.
