356 Parameter listing and descriptions
ACH550-02 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
40 PROCESS GAIN 4001 2.5 0.7 0.7 2.5 2.5 2.5
PID SET 1
INTEGRATION
TIME
4002 3.0 s 10.0 s 10.0 s 3.0 s 3.0 s 3.0 s
DERIVATION
TIME
4003 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
PID DERIV
FILTER
4004 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s
ERROR
VALUE INV
4005 NO NO NO NO NO NO
UNITS4006%%%%%%
UNIT SCALE4007111111
0% VALUE 4008 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
100% VALUE 4009 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
SET POINT
SEL
4010 KEYPAD KEYPAD KEYPAD KEYPAD KEYPAD KEYPAD
INTERNAL
SETPNT
4011 40.0% 40.0% 40.0% 40.0% 40.0% 40.0%
SETPOINT
MIN
4012 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
SETPOINT
MAX
4013 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
FBK SEL
4014 ACT1 ACT1 ACT1 ACT1 ACT1 ACT1
FBK
MULTIPLIER
4015 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
ACT1 INPUT 4016 AI2 AI2 AI2 AI2 AI2 AI2
ACT2 INPUT 4017 AI2 AI2 AI2 AI2 AI2 AI2
ACT1
MINIMUM
4018 0% 0% 0% 0% 0% 0%
ACT1
MAXIMUM
4019 100% 100% 100% 100% 100% 100%
ACT2
MINIMUM
4020 0% 0% 0% 0% 0% 0%
ACT2
MAXIMUM
4021 100% 100% 100% 100% 100% 100%
SLEEP
SELECTION
4022 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
PID SLEEP
LEVEL
4023 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz
PID SLEEP
DELAY
4024 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s
WAKE-UP
DEV
4025 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
WAKE-UP
DELAY
4026 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s
PID 1 PARAM
SET
4027 SET 1 SET 1 SET 1 SET 1 SET 1 SET 1
