Parameter listing and descriptions 185
ACH550-02 User's Manual
0412 PREVIOUS FAULT 1 as par. 0401
Fault code of the second last fault. Read-only.
0413 PREVIOUS FAULT 2 as par. 0401
Fault code of the third last fault. Read-only.
