Parameter listing and descriptions 255
ACH550-02 User's Manual
3205 SUPERV 2 LIM LO -
Sets the low limit for the second supervised parameter. See 3204
SUPERV 2 PARAM above.
3206 SUPERV 2 LIM HI -
Sets the high limit for the second supervised parameter. See 3204
SUPERV 2 PARAM above.
3207 SUPERV 3 PARAM 101…178
Selects the third supervised parameter. See 3201
SUPERV 1 PARAM
above.
3208 SUPERV 3 LIM LO -
Sets the low limit for the second supervised parameter. See 3207
SUPERV 3 PARAM above.
3209 SUPERV 3 LIM HI -
Sets the high limit for the third supervised parameter. See 3207
SUPERV 3 PARAM above.
