Parameter listing and descriptions 295
ACH550-02 User's Manual
5131 FBA STATUS 0…6
Contains the status of the adapter module.
0 =
IDLE – Adapter not configured.
1 =
EXECUT INIT – Adapter is initializing.
2 =
TIME OUT – A time-out has occurred in the communication between
the adapter and the drive.
3 =
CONFIG ERROR – Adapter configuration error.
• The major or minor revision code of the adapter’s CPI firmware
revision differs from that stated in the drive’s configuration file.
4 =
OFF-LINE – Adapter is off-line.
5 =
ON-LINE – Adapter is on-line.
6 =
RESET – Adapter is performing a hardware reset.
5132 FBA CPI FW REV 0…0xFFFF
Contains the revision of the module’s CPI program. Format is xyz,
where:
• x = major revision number
• y = minor revision number
• z = correction number.
Example: 107 = revision 1.07
5133 FBA APPL FW REV 0…0xFFFF
Contains the revision of the module’s application program. Format is
xyz, where:
• x = major revision number
• y = minor revision number
• z = correction number.
Example: 107 = revision 1.07
