360 Parameter listing and descriptions
ACH550-02 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
42 EXT / TRIM GAIN 4201 1.0 1.0 1.0 1.0 1.0 1.0
PID
INTEGRATION
TIME
4202 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s
DERIVATION
TIME
4203 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
PID DERIV
FILTER
4204 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s
ERROR
VALUE INV
4205 NO NO NO NO NO NO
UNITS4206%%%%%%
UNIT SCALE4207111111
0% VALUE 4208 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
100% VALUE 4209 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
SET POINT
SEL
4210 AI1 AI1 AI1 AI1 AI1 AI1
INTERNAL
SETPNT
4211 40.0% 40.0% 40.0% 40.0% 40.0% 40.0%
SETPOINT
MIN
4212 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
SETPOINT
MAX
4213 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
FBK SEL 4214 ACT1 ACT1 ACT1 ACT1 ACT1 ACT1
FBK
MULTIPLIER
4215 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
ACT1 INPUT 4216 AI2 AI2 AI2 AI2 AI2 AI2
ACT2 INPUT 4217 AI2 AI2 AI2 AI2 AI2 AI2
ACT1
MINIMUM
4218 0% 0% 0% 0% 0% 0%
ACT1
MAXIMUM
4219 100% 100% 100% 100% 100% 100%
ACT2
MINIMUM
4220 0% 0% 0% 0% 0% 0%
ACT2
MAXIMUM
4221 100% 100% 100% 100% 100% 100%
ACTIVATE 4228 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
OFFSET 4229 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
TRIM MODE 4230 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
TRIM SCALE 4231 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
CORRECTION
SRC
4232 PID2 REF PID2 REF PID2 REF PID2 REF PID2 REF PID2 REF
45 ENERGY
ENERGY
PRICE
4502000000
SAVING
CO2 CONV
FACTOR
4507 0.5 0.5 0.5 0.5 0.5 0.5
PUMP
POWER
4508 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
ENERGY
RESET
4509 DONE DONE DONE DONE DONE DONE
