348 Parameter listing and descriptions
ACH550-02 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
31 AUTOMATIC
NUMBER OF
TRIALS
3101555555
RESET
TRIAL TIME 3102 30.0 s 30.0 s 30.0 s 30.0 s 30.0 s 30.0 s
DELAY TIME 3103 6.0 s 6.0 s 6.0 s 6.0 s 6.0 s 6.0 s
AR OVER-
CURRENT
3104 DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE
AR OVER-
VOLTAGE
3105 ENABLE ENABLE ENABLE ENABLE ENABLE ENABLE
AR UNDER-
VOLTAGE
3106 ENABLE ENABLE ENABLE ENABLE ENABLE ENABLE
AR AI<MIN 3107 ENABLE ENABLE ENABLE ENABLE ENABLE ENABLE
AR
EXTERNAL
FLT 3108 ENABLE ENABLE ENABLE ENABLE ENABLE ENABLE
32 SUPER-
SUPERV 1
PARAM
3201
OUTPUT
FREQ
OUTPUT
FREQ
OUTPUT
FREQ
OUTPUT
FREQ
OUTPUT
FREQ
OUTPUT
FREQ
VISION
SUPERV 1
LIM LO
3202 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz
SUPERV 1
LIM HI
3203 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz
SUPERV 2
PARAM
3204 CURRENT CURRENT CURRENT CURRENT CURRENT CURRENT
SUPERV 2
LIM LO
3205------
SUPERV 2
LIM HI
3206------
SUPERV 3
PARAM
3207 TORQUE TORQUE TORQUE TORQUE TORQUE TORQUE
SUPERV 3
LIM LO
3208 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
SUPERV 3
LIM HI
3209 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
33 INFOR- FIRMWARE 3301
Firmware
version
Firmware
version
Firmware
version
Firmware
version
Firmware
version
Firmware
version
MATION
LOADING
PACKAGE
3302000000
TEST DATE3303000000
DRIVE
RATING
3304------
PARAMETER
TABLE
3305
Par. table
version
Par. table
version
Par. table
version
Par. table
version
Par. table
version
Par. table
version
