Preparing for installation 41
ACH550-02 User’s Manual
Analogue cables
Recommendations for analogue signal runs:
• Use double shielded, twisted-pair cable.
• Use one individually shielded-pair for each signal.
• Do not use a common return for different analogue signals.
• Earth at one end only.
Digital cables
Recommendations for digital signal runs:
• A double shielded cable is the best alternative, but a single
shielded twisted multi-pair cable is also usable.
Control panel (operator keypad) cable
If the control panel is connected to the drive with a cable, use
only twisted-pair, ethernet cable. Maximum length is 3 meters.
