ABB ACH550-02-645A-4 [260/454] Group 33 information
![ABB ACH550-02-645A-4 [260/454] Group 33 information](/views2/1557008/page260/bg104.png)
256 Parameter listing and descriptions
ACH550-02 User's Manual
Group 33: INFORMATION
This group provides access to information about the drive’s
current programs: versions and test date.
Code Description Range
3301 FIRMWARE 0000…FFFF hex
Contains the version of the drive’s firmware.
3302 LOADING PACKAGE 0000…FFFF hex
Contains the version of the loading package.
3303 TEST DATE yy.ww
Contains the test date (yy.ww).
3304 DRIVE RATING XXXY
Indicates the drive’s current and voltage rating. The format is XXXY,
where:
• XXX = The nominal current rating of the drive in amperes. If present,
an “A” indicates a decimal point in the rating for the current. For
example XXX = 8A8 indicates a nominal current rating of 8.8 A.
• Y = The voltage rating of the drive, where Y = 2 indicates a
208…240 V rating, and Y = 4 indicates a 380…480 V rating.
3305 PARAMETER TABLE 0000…FFFF hex
Contains the version of the parameter table used in the drive.
